2025 Volvo EX40
Twin Motor AWD Core
MSRP: $54,250
Previous
Next
Trims
2025 Volvo EX40
Standard Equipment
2025 Volvo EX40 Available Options
- Cloud Blue
- Crystal White Pearl
- Onyx Black Metallic
- Fjord Blue Metallic
- Silver Dawn Metallic
- Vapour Grey Metallic
- Sand Dune Metallic
- Sage Green Metallic
- Charcoal, City Canvas Textile Upholstery
- Charcoal, Fusion Microtech/Textile Upholstery, -inc: Interior High-Level Illumination
- Dawn, Fusion Microtech/Textile Upholstery, -inc: Interior High-Level Illumination
- Climate Package, -inc: Heated Steering Wheel, Heated Rear Seats, Heat Pump
- Protection Package Premier, -inc: Cargo Tray, Rubber Floor Mats, First Aid Kit, Wheel Locks, (PIO)
- Protection Package, -inc: Cargo Tray, All-Weather Floor Mats, (PIO)
- Trailer Hitch, -inc: Excluding ball and ball holder, (PIO)
- Trunk Spoiler, (PIO)
- Front & Rear Mud Flaps, (PIO)
- Running Boards, (PIO)
- Digital Rearview Mirror w/HomeLink, (PIO)
- Load Bars, (PIO)
2025 Volvo EX40 Consumer Information
2025 Volvo EX40 Technical Specifications
- Body Style: Sport Utility
- EPA Classification: Small SUV 4WD
- EPA Greenhouse Gas Score: 10.0
- Wt Distributing Hitch – Max Trailer Wt.: 2000 lbs
- Wt Distributing Hitch – Max Tongue Wt.: 200 lbs
- Trans Type: 1
- Trans Description Cont.: Automatic
- Reverse Ratio (:1): N/A
- Disc – Front (Yes or ): Yes
- Disc – Rear (Yes or ): Yes
- Drivetrain: All Wheel Drive
- First Gear Ratio (:1): 8.57
- Final Drive Axle Ratio (:1): N/A
- Transfer Case Gear Ratio (:1), High: N/A
- Transfer Case Gear Ratio (:1), Low: N/A
- SAE Net Horsepower: 402
- SAE Net Torque: 494
- Engine Type: Electric
- SAE Net Horsepower @ RPM: 402
- SAE Net Torque @ RPM: 494
- Head Room (in): 37.6
- Leg Room (in): 40.9
- Passenger Capacity: 5
- Front Head Room: 37.6 in
- Front Leg Room: 40.9 in
- Front Shoulder Room: 56.7 in
- Front Hip Room: 54.7 in
- Second Head Room: 38.3 in
- Second Leg Room: 36.1 in
- Second Shoulder Room: 56.3 in
- Second Hip Room: 54.6 in
- EPA MPG Equivalent – City: 103.0
- EPA MPG Equivalent – Hwy: 85.0
- Base Curb Weight: 4670 lbs
- Dead Weight Hitch – Max Trailer Wt.: 2000 lbs
- Dead Weight Hitch – Max Tongue Wt.: 200 lbs
- Turning Diameter – Curb to Curb: 37.4 ft
- Total Option Weight: 0.00 lbs
- Maximum Trailering Capacity: 2000 lbs
- Cargo Volume to Seat 1: 57.5 cu ft
- Cargo Volume to Seat 2: 16 cu ft
- Front Tire Size: P235/50HR19
- Rear Tire Size: P255/45HR19
- Front Wheel Size: 19 X 7.5 in
- Rear Wheel Size: 19 X 7.5 in
- Front Wheel Material: Aluminum
- Rear Wheel Material: Aluminum
- Suspension Type – Front: Strut
- Suspension Type – Rear: Multi-Link
- Suspension Type – Front (Cont.): Strut
- Suspension Type – Rear (Cont.): Multi-Link
- Steering Type: Rack-Pinion
- Steering Ratio (:1), Overall: N/A
- Brake Type: 4-Wheel Disc
- Brake ABS System: 4-Wheel
- Front Brake Rotor Diam x Thickness: 13.6 in
- Rear Brake Rotor Diam x Thickness: 13.4 in
- Wheelbase: 106.4 in
- Length, Overall: 174.8 in
- Width, Max w/o mirrors: 75.2 in
- Height, Overall: 65.2 in
- Track Width, Front: 63 in
- Track Width, Rear: 63.6 in
- Min Ground Clearance: 6.9 in
- Cargo Area Length @ Floor to Seat 1: 65.7 in
- Cargo Area Length @ Floor to Seat 2: 34.9 in
- Cargo Area Width @ Beltline: 41.7 in
- Cargo Box Width @ Wheelhousings: 39.5 in
- Liftover Height: 29.7 in
- Estimated Battery Range: 260.0 mi
- Usable/net Traction Battery Capacity (kWh): 79.0
- Gross Traction Battery Capacity (kWh): 82.0
- Cold Cranking Amps @ 0deg F (Primary): 760
