2023 Jeep Grand Wagoneer L
Series III Obsidian 4x4
MSRP: $113,095
Previous
Next
Trims
2023 Jeep Grand Wagoneer L
Standard Equipment
2023 Jeep Grand Wagoneer L Available Options
- Engine: 3.0L I6 Hurricane HO Twin Turbo ESS, (STD)
- Transmission: 8-Speed Automatic (8HP75), (STD)
- Quick Order Package 28T Obsidian, -inc: Engine: 3.0L I6 Hurricane HO Twin Turbo ESS, Transmission: 8-Speed Automatic (8HP75), Gloss Black Upper & Lower DLO Molding, Obsidian Appearance Package, Black Interior Accents, Black Roof, Piano Black Exterior Accents
- Tires: 285/45R22XL BSW All Season, (STD)
- Bright White Clearcoat
- Ember Pearlcoat, Build Out:02/06/2023
- Baltic Gray Metallic Clearcoat
- Midnight Sky
- Silver Zynith
- Diamond Black Crystal Pearlcoat
- Global Black, Premium Leather Trimmed Bucket Seats
- Tupelo/Black, Premium Leather Trimmed Bucket Seats
- Blue Agave, Premium Leather Trimmed Bucket Seats
- GVWR: 7,800 lbs, (STD)
- GVWR: 7,950 lbs
- Rear Seat Video Group 1, -inc: Video USB Port, Seatback Video Screens, Amazon Fire TV Built-In
- Flexible Seating Group, -inc: 2nd Row Dual Charge-Only USB Ports, 8 Passenger Seating, 40/20/40 Power Recline Tip/Slide, GVWR: 7,950 lbs
- HD Trailer Tow Package, -inc: Removable Rear Tow Hook, Trailer Brake Control, Trailer Hitch Zoom, Heavy Duty Engine Cooling, Black Tow Hooks
- MOPAR Interior Protection Package, -inc: All-Season Floor Mats, Cargo Tray
- Body Color Roof w/2_T
- Destination Surcharge (Hawaii), (Regional)
2023 Jeep Grand Wagoneer L Consumer Information
2023 Jeep Grand Wagoneer L Technical Specifications
- Engine: 3.0L I6 Hurricane HO Twin Turbo ESS
- (STD)
- Engine Type: 3.0L I6 Hurricane HO Twin Turbo ESS
- SAE Net Horsepower: 510
- SAE Net Torque: 500
- EPA Fuel Economy Est – Hwy: 19 MPG
- EPA Fuel Economy Est – City: 14 MPG
- Fuel Economy Est-Combined: 16 MPG
- Engine Order Code: EFC
- Engine Type: Twin Turbo Premium Unleaded I-6
- Displacement: 3.0 L/183
- Fuel System: Gasoline Direct Injection
- SAE Net Horsepower @ RPM: 510 @ 5700
- SAE Net Torque @ RPM: 500 @ 3500
- Engine Oil Cooler: None
- Fuel Tank Capacity, Approx: 30.5 gal
- Transmission: 8-Speed Automatic (8HP75)
- (STD)
- Drivetrain: Four Wheel Drive
- First Gear Ratio (:1): 4.71
- Second Gear Ratio (:1): 3.14
- Third Gear Ratio (:1): 2.11
- Fourth Gear Ratio (:1): 1.67
- Fifth Gear Ratio (:1): 1.28
- Sixth Gear Ratio (:1): 1.00
- Final Drive Axle Ratio (:1): N/A
- Transfer Case Gear Ratio (:1), High: N/A
- Transfer Case Gear Ratio (:1), Low: N/A
- Axle Type – Front: Independent
- Axle Type – Rear: Independent
- Axle Ratio (:1) – Front: 3.92
- Axle Ratio (:1) – Rear: 3.92
- Seventh Gear Ratio (:1): 0.84
- Eighth Gear Ratio (:1): 0.67
- Body Style: Sport Utility
- Tons/yr of CO2 Emissions @ 15K mi/year: 11.1
- Gross Combined Wt Rating: 12300 lbs
- Wt Distributing Hitch – Max Trailer Wt.: 5400 lbs
- Wt Distributing Hitch – Max Tongue Wt.: 540 lbs
- Trans Order Code: DFR
- Trans Type: 8
- Trans Description Cont.: Automatic w/OD
- Reverse Ratio (:1): 3.29
- Transfer Case Model: Electronic
- Transfer Case Power Take Off: No
- Disc – Front (Yes or ): Yes
- Disc – Rear (Yes or ): Yes
- Head Room (in): 39.3
- Leg Room (in): 40.9
- Passenger Capacity: 7
- Front Head Room: 39.3 in
- Front Leg Room: 40.9 in
- Front Shoulder Room: 66.1 in
- Front Hip Room: 63.4 in
- Second Head Room: 38.4 in
- Second Leg Room: 42.7 in
- Second Shoulder Room: 65.2 in
- Second Hip Room: 63 in
- Third Head Room: 38.5 in
- Third Leg Room: 36.6 in
- Third Shoulder Room: 64.4 in
- Third Hip Room: 51.6 in
- Fuel Economy Est-Combined: 16
- Cruising Range – City: 427.00 mi
- Cruising Range – Hwy: 579.50 mi
- Standard Weight – Front: 0.00 lbs
- Standard Weight – Rear: 0.00 lbs
- Base Curb Weight: 6704 lbs
- Option Weight – Front: 0.00 lbs
- Option Weight – Rear: 0.00 lbs
- Dead Weight Hitch – Max Trailer Wt.: 5000 lbs
- Dead Weight Hitch – Max Tongue Wt.: 500 lbs
- Turning Diameter – Curb to Curb: 42.2 ft
- Total Option Weight: 0.00 lbs
- Gross Vehicle Weight Rating: 7800.00 lbs
- Maximum Trailering Capacity: 5400 lbs
- Cargo Volume to Seat 1: 112.9 cu ft
- Cargo Volume to Seat 2: 88.8 cu ft
- Cargo Volume to Seat 3: 44.2 cu ft
- Payload Weight Front: 0 lbs
- Payload Weight Rear: 0 lbs
- Front Tire Order Code: TAR
- Rear Tire Order Code: TAR
- Front Tire Size: P285/45TR22
- Rear Tire Size: P285/45TR22
- Spare Tire Size: Full-Size
- Front Wheel Size: 22 X 9 in
- Rear Wheel Size: 22 X 9 in
- Spare Wheel Size: Full-Size in
- Front Wheel Material: Aluminum
- Rear Wheel Material: Aluminum
- Spare Wheel Material: Steel
- Maximum Alternator Capacity (amps): 230
- Cold Cranking Amps @ 0deg F (Primary): 700
- Cold Cranking Amps @ 0deg F (2nd): 700
- Suspension Type – Front: Short And Long Arm
- Suspension Type – Rear: Multi-Link
- Steering Type: Rack-Pinion
- Steering Ratio (:1), Overall: N/A
- Steering Ratio (:1), On Center: N/A
- Steering Ratio (:1), At Lock: N/A
- Brake Type: 4-Wheel Disc
- Brake ABS System: 4-Wheel
- Brake ABS System (Second Line): 4-Wheel
- Front Brake Rotor Diam x Thickness: 14.9 in
- Rear Brake Rotor Diam x Thickness: 14.8 in
- Wheelbase: 130 in
- Length, Overall: 226.7 in
- Width, Max w/o mirrors: 83.6 in
- Height, Overall: 75.6 in
- Track Width, Front: 68.4 in
- Track Width, Rear: 68.3 in
- Min Ground Clearance: 10 in
- Body Length: 0.00 ft
- Liftover Height: 31.9 in
