2026 Volvo XC40
B5 AWD Ultra
MSRP: $51,250
Previous
Next
Trims
2026 Volvo XC40
Standard Equipment
2026 Volvo XC40 Available Options
- Monotone Paint
- Cloud Blue
- Crystal White
- Onyx Black
- Denim Blue
- Vapour Grey Metallic
- Sand Dune Metallic
- Aurora Silver
- Forest Lake
- Charcoal, Leather Seating Surfaces
- Blonde, Leather Seating Surfaces w/Blonde Interior
- Charcoal, Connect Suede Textile/Microtech Seating Surfaces
- Climate Package, -inc: Heated Rear Seats, Heated Steering Wheel
- Wheels: 21″ 5 Spoke, -inc: Tires: 21″ All Season, (PIO)
- Tires: 21″ All Season, (PIO)
- Protection Package Premier, -inc: Cargo Tray, Rubber Floor Mats, First Aid Kit, Wheel Locks, (PIO)
- Protection Package, -inc: Cargo Tray, All-Weather Floor Mats, (PIO)
- Trailer Hitch, -inc: Excluding ball and ball holder, (PIO)
- Trunk Spoiler, (PIO)
- Front & Rear Mud Flaps, (PIO)
- Running Boards, (PIO)
- Digital Rearview Mirror w/HomeLink, (PIO)
- Load Bars, (PIO)
2026 Volvo XC40 Consumer Information
2026 Volvo XC40 Technical Specifications
- Body Style: Sport Utility
- Tons/yr of CO2 Emissions @ 15K mi/year: 6.7
- EPA Classification: Small SUV 4WD
- EPA Greenhouse Gas Score: 5.0
- Wt Distributing Hitch – Max Trailer Wt.: 3500 lbs
- Wt Distributing Hitch – Max Tongue Wt.: 350 lbs
- Trans Type: 8
- Trans Description Cont.: Automatic w/OD
- Reverse Ratio (:1): 3.99
- Disc – Front (Yes or ): Yes
- Disc – Rear (Yes or ): Yes
- Drivetrain: All Wheel Drive
- First Gear Ratio (:1): 5.06
- Second Gear Ratio (:1): 3.07
- Third Gear Ratio (:1): 2.05
- Fourth Gear Ratio (:1): 1.52
- Fifth Gear Ratio (:1): 1.26
- Sixth Gear Ratio (:1): 1.00
- Final Drive Axle Ratio (:1): 3.33
- Transfer Case Gear Ratio (:1), High: N/A
- Transfer Case Gear Ratio (:1), Low: N/A
- Seventh Gear Ratio (:1): 0.79
- Eighth Gear Ratio (:1): 0.66
- SAE Net Horsepower: 247
- SAE Net Torque: 258
- EPA Fuel Economy Est – Hwy: 30 MPG
- EPA Fuel Economy Est – City: 23 MPG
- Fuel Economy Est-Combined: 26 MPG
- Engine Type: Intercooled Turbo Gas/Electric I-4
- Displacement: 2.0 L/120
- Fuel System: Gasoline Direct Injection
- SAE Net Horsepower @ RPM: 247 @ 5500
- SAE Net Torque @ RPM: 258 @ 1800
- Fuel Tank Capacity, Approx: 14.2 gal
- Head Room (in): 37.6
- Leg Room (in): 40.9
- Passenger Capacity: 5
- Front Head Room: 37.6 in
- Front Leg Room: 40.9 in
- Front Shoulder Room: 56.7 in
- Front Hip Room: 54.7 in
- Second Head Room: 38.3 in
- Second Leg Room: 36.1 in
- Second Shoulder Room: 56.3 in
- Second Hip Room: 54.6 in
- Fuel Economy Est-Combined: 26
- Cruising Range – City: 326.60 mi
- Cruising Range – Hwy: 426.00 mi
- Base Curb Weight: 3966 lbs
- Dead Weight Hitch – Max Trailer Wt.: 3500 lbs
- Dead Weight Hitch – Max Tongue Wt.: 350 lbs
- Turning Diameter – Curb to Curb: 37.4 ft
- Total Option Weight: 0.00 lbs
- Maximum Trailering Capacity: 3500 lbs
- Cargo Volume to Seat 1: 57.5 cu ft
- Cargo Volume to Seat 2: 16 cu ft
- Front Tire Size: P245/45HR20
- Rear Tire Size: P245/45HR20
- Spare Tire Size: Compact
- Front Wheel Size: 20 X 8 in
- Rear Wheel Size: 20 X 8 in
- Spare Wheel Size: Compact in
- Front Wheel Material: Aluminum
- Rear Wheel Material: Aluminum
- Spare Wheel Material: Steel
- Suspension Type – Front: Strut
- Suspension Type – Rear: Multi-Link
- Suspension Type – Front (Cont.): Strut
- Suspension Type – Rear (Cont.): Multi-Link
- Steering Type: Rack-Pinion
- Steering Ratio (:1), Overall: N/A
- Brake Type: 4-Wheel Disc
- Brake ABS System: 4-Wheel
- Front Brake Rotor Diam x Thickness: 13.6 in
- Rear Brake Rotor Diam x Thickness: 11.9 in
- Wheelbase: 106.4 in
- Length, Overall: 174.8 in
- Width, Max w/o mirrors: 75.2 in
- Height, Overall: 65.2 in
- Track Width, Front: 63 in
- Track Width, Rear: 64 in
- Min Ground Clearance: 8.3 in
- Cargo Area Length @ Floor to Seat 1: 65.7 in
- Cargo Area Length @ Floor to Seat 2: 34.9 in
- Cargo Area Width @ Beltline: 41.7 in
- Cargo Box Width @ Wheelhousings: 37.3 in
- Cargo Box (Area) Height: 29.4 in
- Liftover Height: 29.7 in
- Cold Cranking Amps @ 0deg F (Primary): 760
